Expanded Mesh

وصف المنتج

Expanded metal mesh is a metal sheet mesh with uniform holes that is formed by stretching and expanding a metal sheet through equipment. It is collectively called metal stretched mesh. Due to the different hole shapes, it is also called: diamond stretched mesh, hexagonal stretched mesh, Also known as: stainless steel stretched wire mesh, low carbon steel stretched wire mesh, aluminum plate stretched wire mesh, etc.

مواصفات المنتج

Plate thickness(mm)Hole width(mm)Hole length(mm)StemMesh width(m)Mesh length(m)Weight(kg/m²)
0.52.54.50.50.511.8
0.510250.50.620.73
0.6102510.621
0.8102510.621.25
110251.10.621.77
115401.5241.85
1.210251.1242.21
1.215401.5242.3
1.515401.51.842.77
1.523602.623.62.77
218502.1243.69
222602.6243.69
340803.8245.00
45010042211.15
4.550100522.711.15
55010051.42.612.39



MaterialStainless Steel, Low Carbon Aluminum, Low carbon steel, Galvanized steel, Stainless steel, Copper, Titanium etc
LWDMAX 300mm
SWDMAX 120mm
Stem0.5mm-8m
Sheet widthMAX 3.4m
Thickness0.5mm – 14mm
SurfaceTreatment- Mill Finish- Anodized (colour can be customized)- Powder coated- PVDF- Spray painted- Galvanized : Electric galvanized, Hot-dipped galvanized
Classification- Small expanded wire mesh- Medium expanded wire mesh- Heavy expanded wire mesh- Diamond expanded wire mesh- Hexagonal expanded wire mesh- Special expanded
UseExpended metal mesh can be widely used in including the protection of machinery equipment, handicraftmanufacturing, shelves, heavy machinery, workplatforms, walkways, ships as well as other areas.

تفاصيل المنتج

نوع المنتج:

Surface Treatment: Powder Coated, hot dipped galvanized, anodizing, etc.

Application:

1. Aerospace: Nacelles, fuel filters, air filters

2. Appliances: Dish washer strainers, microwave screens, dryer and washer drums, cylinders for gas burners, water heaters and heat pumps.

3. Architectural: Stairs, ceilings, walls, floors, shades, decorative, sound absorption

4. Automotive: Fuel filters, speakers, muffler guards, protective radiator grills

5. Hammer mill: Screens for sizing and separating

6. Industrial equipment: Conveyors, dryers, heat dispersion, guards, EMI/RFI protection

7. Pollution control: filters, separators

8. Mining: Screens

9. Security: Screens, walls, doors, ceilings, guards

10. Sugar processing: centrifuge screens, mud filter screens, backing screens, filter leaves, diffuser drainage plates.

Product Feature

Product Feature

The mesh is uniform, the surface of the net is smooth and the coefficient of friction is-high, the strength is bin, the strength is strong, the beauty is beautiful. easy to-maintain and the visibility is good.

1. Corrosion resistance

2. Durable

3. Reliable Coating

4. Cost-Effective

5. Fast Turnaround

6. Beautiful

Product Packing & Shipping

Product Packing & Shipping

Packaging:

1. Packed by pallet.

2. Waterproof paper in rolls.

3. Custom packing available at your request.

Shipping:

We have long-term cooperation with many experienced shipping companies and will find the most suitable mode of transportation for you.

التعليمات

Q: When can we get your reply?

A: Within 1 hours after get your inquiry.

Q: How to make an inquiry of Expanded Wire Mesh?

A: You need to provide material, sheet size, LWD SWD and the quantity to ask an offer. You can also indicate if you have any special requirement .

Q: Could you provide free sample?

A: Yes, we can provide free sample in half A4 size together with our catalogue. But the courier charge will on your side. We'll send back the courier charge if you make an order.

Q: What types of materials are made into expanded metal sheet?

A: There are many types of materials made into expanded metal sheet. For example, aluminum, carbon steel, stainless steel, nickel, silver and copper can all be made into expanded metal sheets.

Q: What about the delivery time?

A: Normally 7-25 days, will depends on order quantity.

Q: How is your Payment Term?

A: Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of B/L.Other payment term we can also discuss.
